BLADE - GATOR MULCHER, 22.50"-GAT-F-CW 46" & 66" CUT SIDE DISCHARGE (Sold per blade)

Genuine BigDog 46" Cut & HUSTLER 66" Cut Gator Mulcher Bar Blade

Genuine Hustler and BigDog Gator mulcher bar blade. Fitted as a service replacementblade on the models listed below where a mulching blade is required. The Gatormulcher blade (GAT) has grooves cut into the blade sail to create multiple edgeswhere the material can be recut. It can be used in catching, side discharge andmulching modes and is particularly effective in reducing the volume of grass anddry leaves left after cutting.

BigDog 798512HUSTLER 798512

0.63"

16.002 mm

46" & 66" cut

1168.4 mm cut & 1676.4 mm cut

116.8 & 167.6 cm cut

22.50"

571.5 mm

0.203"

5.156 mm

3"

76.2 mm

Round

46" (1168 mm) cut BigDog C Series (models BDU931451EX and BDU933580EX) sidedischarge zero turn radius (ZTR) models.

2

66" (1676.4 mm) cut HUSTLER Super Z (models HU932657EX and HU935494EX) and Super ZHyperdrive (model HU937102EX) side discharge zero turn radius (ZTR) models.

3

Gator mulcher flat blade, clockwise rotation. the sharpened slots in the bladesails / flute area cuts and recuts the grass,

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, Gator Mulcher Blade, Mulching Blade,
