BLADE - WAVY MULCHER, 23.86"-MUL-F-CW 72" & 104" CUT SIDE DISCHARGE (Sold per blade)

Genuine BigDog & HUSTLER 72" & 104" Cut Wavy Mulcher Bar Blade

Genuine Hustler and BigDog wavy mulcher bar blade. Fitted as a service replacementblade on the models listed below where a mulching blade is required. The wavymulcher blade (MUL) has both a positive lift on the outside of the blade and anegative lift toward the inside of the blade. This serves to agitate the grassinside the deck to bring it into more contact with the cutting surfaces and therebyreduce clipping size. While this is primarily for decks with mulching kitsinstalled, using a wavy mulch blade in side discharge mode also reduces clippingsize.

BigDog 793398HUSTLER 793398

0.63"

16.002 mm

72" & 104" cut

1829 mm & 2641.6 mm cut

182.9 cm & 264.1 cm cut

23.86"

606 mm

0.203"

5.156 mm

3"

76.2 mm

Round

72" (1829 mm) cut BigDog Diablo MP (models BDU933275EX, BDU935106EX andBDU936443EX) side discharge zero turn radius (ZTR) models.

3

104" (2641.6 mm) cut HUSTLER Super 104 (models HU931733EX, HU938910EX andHU939603EX and HU940544EX *on the right hand side deck only) zero turn radius (ZTR)models.

*For the centre rear discharge decks use HP794214 x 2 qty and HP604163 x 1 qty -for left hand side deck use HP604164 x 1 qty, for right hand side deck use HP793398x 1 qty.

Wavy mulcher blade, clockwise rotation. Cuts and recuts the grass reducing clippingsize.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
