FUSION BLADE LOW LIFT, F23.86-L-F-CCW 72" & 104" CUT REAR DISCHARGE (Sold per blade)

Genuine HUSTLER 72" & 104" Cut, Rear Discharge Low Lift Fusion Bar Blade

Genuine Hustler low lift Fusion bar blade. Fitted as a service replacement blade onmodels listed below where a low lift blade is required. Blade Lift refers to theability of a blade to provide vacuum to lift grass so that it can be cut uniformly.More blade lift also contributes to removing debris out of the grass, clearingdebris out of the deck and throwing the grass further in side discharge mode. Insome conditions, more blade lift can result in causing debris to build up under thedeck, while in other conditions, the opposite is true. Blade "Lift" can be measuredfrom the bottom side of the blade to the highest point of the blade sail. A LowLift Blade (L) is adequate for shallow decks and most consumer applications and canbe used to reduce blowout or deck packing in some conditions. Blade lift for thisblade measures 0.79" (20.066 mm). Fusion blades feature an exclusive electro-fusiontechnology that creates an ultra-hard layer at the blade’s cutting edge, theblade remains sharp and continues to give a clean cut far longer than any blade onthe market.

HUSTLER 796508

0.63"

16.002 mm

72" & 104" cut

1829 mm & 2642 mm

182.9 cm & 264.15 cm

23.86"

606 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Flute/sail height 0.79"

Flute/sail height 20.066 mm

Round

72" (1829 mm) cut HUSTLER 3700 (*HU928713EX) rear discharge zero turn radius (ZTR)models.

*Use HP7696839 x 2 qty and HP796508 x 1 qty.

104" (2642 mm) cut HUSTLER Super 104 (models HU931733EX, HU938910EX and HU940544EX*on the left hand side deck only) zero turn radius (ZTR) models.

For the centre rear discharge decks use HP600901 x 2 qty and HP795633 x 1 qty (Formodels HU931733EX and HU938910EX use with - for left hand side deck use HP796508 x1 qty, for right hand side deck use HP796839 x 1 qty).

Low lift, flat Fusion blade, counter clockwise rotation (flute/sail height 0.79"/20.066 mm). Fusion blades feature an exclusive electro-fusion technology thatcreates an ultra-hard layer at the blade’s cutting edge, the blade remains sharpand continues to give a clean cut far longer than any blade on the market.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

HUSTLER

Bar Blade, Blade Bar, Low Lift Bar Blade,
