FUSION BLADE LOW LIFT, F23.86"-L-F-CW 72" & 104" CUT SIDE & REAR DISCHARGE (Sold per blade)

Genuine BigDog & HUSTLER 72" & 104" Cut, Side and Rear Discharge Low Lift FusionBar Blade

Genuine Hustler and BigDog low lift Fusion bar blade. Fitted as a production lineblade on selected *Super 104 models (*on the right hand side deck only). Fitted asa service replacement blade on other models listed below where a low lift blade isrequired. Blade Lift refers to the ability of a blade to provide vacuum to liftgrass so that it can be cut uniformly. More blade lift also contributes to removingdebris out of the grass, clearing debris out of the deck and throwing the grassfurther in side discharge mode. In some conditions, more blade lift can result incausing debris to build up under the deck, while in other conditions, the oppositeis true. Blade "Lift" can be measured from the bottom side of the blade to thehighest point of the blade sail. A Low Lift Blade (L) is adequate for shallow decksand most consumer applications and can be used to reduce blowout or deck packing insome conditions. Blade lift for this blade measures 0.79" (20.066 mm). Fusionblades feature an exclusive electro-fusion technology that creates an ultra-hardlayer at the blade’s cutting edge, the blade remains sharp and continues to givea clean cut far longer than any blade on the market.

BigDog 796839HUSTLER 796839

0.63"

16.002 mm

72" & 104" cut

1829 mm & 2641.6 mm

182.9 cm & 264.15 cm

23.86"

606 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Flute/sail height 0.79"

Flute/sail height 20.066 mm

Round

72" (1829 mm) cut BigDog Diablo MP (models BDU933275EX, BDU935106EX, BDU936443EX)side discharge zero turn radius (ZTR) models.

3

72" (1829 mm) cut HUSTLER 3700 (*HU928713EX) rear discharge zero turn radius (ZTR)models.

*Use HP7696839 x 2 qty and HP796508 x 1 qty.

104" (2641.6 mm) cut HUSTLER Super 104 (models HU931733EX, HU938910EX andHU940544EX *on the right hand side deck only) zero turn radius (ZTR) models.

For the centre rear discharge decks use HP600901 x 2 qty and HP795633 x 1 qty (Formodels HU931733EX and HU938910EX use with - for left hand side deck use HP796508 x1 qty, for right hand side deck use HP796839 x 1 qty).

Low lift, flat Fusion blade, clockwise rotation (flute/sail height 0.79"/ 20.066mm). Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
