PROKUT SPROCKET NOSE GUIDE BAR 20 #48 CC

PROKUT™ 20" x 3/8" x .058" x 72 DL, CC Mount, Solid Professional ReplaceableSprocket Nose Guide Bar

OREGON® 208RNDD024

OREGON® 208RNDD024• Nose fastens with a single rivet, and is securely held by wide and strongoverlapping ears• The long sprocket nose takes most of the abuse, and minimizes wear to the barsbody• Super tough chrome-moly steel provides superior bar-body strength and toughrails with excellent resistance to wear and chipping• All PROKUT™ guide bars are reversible for longer life

• Solid professional replaceable sprocket nose guide bar• Nose fastens with a single rivet, and is securely held by wide and strongoverlapping ears• The long sprocket nose takes most of the abuse, and minimizes wear to the barsbody• Super tough chrome-moly steel provides superior bar-body strength and toughrails with excellent resistance to wear and chipping• All PROKUT™ guide bars are reversible for longer life

20"

20"

50 cm

3/8"

Solid Professional Replaceable Sprocket Nose Guide Bar

48S / Semi-Chisel or 48F / Full-Chisel

CC

.058"

72

11 Tooth sprocket nose

50 cc to 100 cc (3.0 to 6.0 cu. in.)

Efco 181, MT 6500, MT 7200 and MT 8200 models.

830, 910, 920, 930, 939, 941, 1020 and 2350 models. Note: Please check your sawcarefully prior to ordering, some of the above saw models were also released fittedwith a .404" pitch chain.

John Deere CS71 and CS81 models.

355, 460A SUPER, 461, 480A SUPER, 970F, 980, 980F, AGRISTAR, GS720, GS820 and SUPER482 models.

Jonsered 60, 61, 62, 66, 70, 75, 77, 80, 81, 90, 110, 111, 601, 621, 751, 801, 820,830, 910, 920, 930, 939, 941, 1020 and 2350 models. Note: Please check your sawcarefully prior to ordering, some of the above saw models were also released fittedwith a .404" pitch chain.

McCulloch ProMac 61 models.

Oleo-Mac 48, 70, 250, 250A, 251, 252, 254, 260, 261, 264, 264F, 272, 280, 284, 350,355, 460A SUPER, 461, 480A SUPER, 970F, 980, 980F, AGRISTAR, GS720, GS820 and SUPER482 models.

Poulan / Poulan Pro PP6120 models.

1

Use with our semi-chisel chain loop part number GAF48S072DL or our full-chiselchain loop part number GAF48F072DL. Replaces our part number OMK208RNDD024

nose guide bar,

1

Use with our semi-chisel chain loop part number GAF48S072DL or our full-chiselchain loop part number GAF48F072DL. Replaces our part number OMK208RNDD024

PROKUT™, GA Forestry Accessories™

Bar, guide bar, solid professional replaceable sprocket nose guide bar, sprocketnose guide bar,
